FuturaSun classic photovoltaic modules

Certified photovoltaic modules



Our high-quality polycrystalline and monocrystalline silicon photovoltaic modules were developed together with FuturaSun and are ideal for battery charging in all stand-alone photovoltaic applications: motorhomes, boats, cabins and other isolated utilities, control systems, road signs, etc.
In addition to these flagship models, OffgridSun is able to offer customised photovoltaic modules at the customer’s specific request.
Contact us for more information.

Stand-Alone

Stand-Alone

Photovoltaic systems suitable for stand-alone installations

certificazione-dekra

Certification

Systems certified to the highest standards

personalizzazioni

Customization

Systems tailored to your needs

YEARS

Product warranty

YEARS

Performance guarantee

MODULO FOTOVOLTAICO POLICRISTALLINO 50 W
Polycrystalline FV module 50 W
1.40 MB

POLYCRYSTALLINE FV MODULE 50 W

POLYCRYSTALLINE 36 CELLS

This small solar panel, consisting of 36 polycrystalline cells, is suitable for campers, boats, cabins and small portable off-grid systems.

  • 12-year product warranty
  • Positive tolerance 0-5 Wp
  • 3.2 mm toughened glass for the best balance between maximum mechanical strength and transparency
  • High mechanical stability (5400 Pa)
  • Maximum hail impact resistance (83 km/h)
  • Water-repellent and anti-reflective treatment to increase performance and reduce dust deposits.
Technical data

  • Cells: 36 polycrystalline silicon
  • Dimensions: 680 x 660 x 35 mm
  • Weight: 4.5 kg
  • Code: FU50P
  • Glass: tempered, transparent, 3.2 mm
  • Cell encapsulant: EVA
  • Backsheet: multi-layer polyester
  • Frame: anodized aluminium, with mounting and drainage holes
  • Junction box is supplied with 60 cm cables, 1 by-pass diode
garanzia-rendimento

Performance guarantee

Max. Decay: 0.7% per year over a 25-year life.
97% at the end of the first year
90% at the end of the 12th year
82% at the end of the 25th year

garanzia-prodotto

Product guarantee

12 years

MODULO FOTOVOLTAICO POLICRISTALLINO 100 W
Polycrystalline FV module 100 W
246.66 KB

POLYCRYSTALLINE FV MODULE 100 W

POLYCRYSTALLINE 36 CELLS

This small solar panel, consisting of 36 polycrystalline cells, is suitable for campers, boats, cabins and small off-grid systems. The 100 W solar module is also installed for small pump systems and street lighting.

  • 12-year product warranty
  • Positive tolerance 0-5 Wp
  • 5 A cells, ideal for off-grid applications
  • 3.2 mm toughened glass for the best balance between maximum mechanical strength and transparency
  • High mechanical stability (5400 Pa)
  • Maximum hail impact resistance (83 km/h)
  • Water-repellent and anti-reflective treatment to increase performance and reduce dust deposits.

Certifications

  • IEC 61215, IEC 61730 & Factory Inspection 2016
  • IEC 668-2-68:1994-08 Dust & Sand Resistance
  • IEC61701:2011 Salt Spray Corrosion Resistance
  • PID Test: Class A Potential Induced Degradation
  • Fire Resistance: Class 1
  • IEC 62716:2013 Ammonia Corrosion
Technical data

  • Cells: 36 polycrystalline silicon 5 busbar
  • Dimensions: 1020 x 670 x 30 mm
  • Weight: 6.8 kg
  • Glass: tempered, transparent, 3.2 mm
  • Cell encapsulant: EVA
  • Backsheet: multi-layer polyester
  • Frame: anodised aluminium, with mounting and drainage holes
  • Junction box can be supplied with or without cables
  • Part number: FU100P3
garanzia-rendimento

Performance guarantee

Max. Decay: 0.7% per year over a 25-year life.
97% at the end of the first year
90% at the end of the 12th year
82% at the end of the 25th year

garanzia-prodotto

Product guarantee

12 years

FU100W-Nova_33-celle_front - Copia
FU100M NOVA
477.97 KB

MONOCRYSTALLINE PV MODULE 100 W

FU100M Nova

This small solar panel, consisting of 33 monocrystalline cells, is suitable for motorhomes, boats, cabins and small off-grid systems. The 100 W solar module is also installed for small pump systems and street lighting.

  • 10-year product warranty
  • Positive tolerance 0-3 Wp
  • 5 A cells, ideal for off-grid applications
  • 3.2 mm toughened glass for the best balance between maximum mechanical strength and transparency
  • High mechanical stability (5400 Pa)
  • Maximum hail impact resistance (83 km/h)
  • anti-reflection, to increase performance and reduce dust deposits.

Certifications

  • IEC 61215, IEC 61730 & Factory Inspection 2016
  • IEC 668-2-68:1994-08 Dust & Sand Resistance
  • IEC61701:2011 Salt Spray Corrosion Resistance
  • PID Test: Class A Potential Induced Degradation
  • Fire Resistance: Class 1
  • IEC 62716:2013 Ammonia Corrosion
Technical data

  • Cells: 33 monocrystalline silicon 5 busbar 182×76 mm
  • Dimensions: 908 x 578 x 30 mm
  • Weight: 6.5 kg
  • Glass: tempered, transparent, 3.2 mm
  • Cell encapsulator: EVA
  • Backsheet: multi-layer polyester
  • Frame: anodised aluminium, with mounting and drainage holes
  • Junction box is supplied with 900 mm cables
  • Code: FU100M Nova
garanzia-rendimento

Performance guarantee

Max. Decay: 0.7% per year over a 25-year life.
98% at the end of the first year
90% at the end of the 12th year
80% at the end of the 25th year

garanzia-rendimento

Product guarantee

10 years

MODULO FOTOVOLTAICO POLICRISTALLINO 165 W
Polycrystalline FV module 165 W
284.02 KB

POLYCRYSTALLINE 165W FV MODULE

POLYCRYSTALLINE 36 CELLS

This small solar panel, consisting of 36 high-efficiency polycrystalline cells with 5 busbars, is suitable for motorhomes, boats, cabins and small off-grid systems. The 160 W solar module is also installed for small pump systems and street lighting.

  • 12-year product warranty
  • High-efficiency cells with 5 busbars reduce current loss and increase power output
  • 3.2 mm toughened glass for the best balance between maximum mechanical strength and transparency
  • High temperature resistance (tested at 105 °C for 200 hours)
  • Very good temperature coefficient of -0.37 %/°C so higher output even at high operating temperatures
  • Applicable in installations up to 7000 metres high
  • Highest hail impact resistance (83 km/h)
  • Quality control with electroluminescence (EL) test on each module
  • 30 mm frame

Certifications

  • IEC 61215, IEC 61730 & Factory Inspection 2016
  • IEC 668-2-68:1994-08 Dust & Sand Resistance
  • IEC61701:2011 Salt Spray Corrosion Resistance
  • PID Test: Class A Potential Induced Degradation
  • Fire Resistance: Class 1
  • IEC 62716:2013 Ammonia Corrosion
Technical data

  • Celle: 36 in silicio policristallino 156×156 mm
  • Dimensioni: 1480 x 670 x 30 mm
  • Peso: 6,8 kg
  • Vetro: temperato, trasparente, 3,2 mm
  • Incapsulante celle: EVA
  • Backsheet: poliestere multistrato
  • Cornice: in alluminio anodizzato, con fori di montaggio e drenaggio
  • 130 x 150 x 26 mm, omologata IP 68
  • Cavi: cavo solare da 900 mm con connettori MC4 compatibili
  • Codice: FU165P
garanzia-rendimento

Performance guarantee

Max. Decay: 0.7% per year over a 25-year life.
97% at the end of the first year
90% at the end of the 12th year
82% at the end of the 25th year

garanzia-prodotto

Product guarantee

12 years

190-M-Nova_Prospettiva - Copia
FU190M NOVA
1.20 MB

MONOCRYSTALLINE PHOTOVOLTAIC MODULE 190 W

FU190M Nova

This small solar panel, consisting of 72 monocrystalline cells, is suitable for campers, boats, cabins and small off-grid systems. The 190 W solar module is also installed for small pump systems and street lighting.

  • 10-year product warranty
  • Positive tolerance 0-5 Wp
  • 5 A cells, ideal for off-grid applications
  • 3.2 mm toughened glass for the best balance between maximum mechanical strength and transparency
  • High mechanical stability (5400 Pa)
  • Maximum hail impact resistance (83 km/h)
  • Water-repellent and anti-reflective treatment to increase performance and reduce dust deposits.
Technical data

  • Cells: 72 182×60,66 mm monocrystalline silicon cells
  • Dimensions: 1250 x 763 x 30 mm
  • Weight: 10,2 kg
  • Glass: tempered, transparent, 3.2 mm
  • Cell encapsulant: EVA
  • Backsheet: multi-layer polyester
  • Frame: anodised aluminium, with mounting and drainage holes
  • Junction box: Certified according to IEC 62790, IP 68 approved
  • Part number: FU190M Nova
garanzia-rendimento

Performance guarantee

Max. Decay: 0.7% per year over a 25-year life.
98% at the end of the first year
90% at the end of the 12th year
80% at the end of the 25th year

garanzia-prodotto

Product guarantee

10 years

Modulo fotovoltaico monocristallino 400W
FuturaSun FU390/395/400/405/410 M Silk® Premium
456.20 KB

400 W MONOCRYSTALLINE PHOTOVOLTAIC MODULE

Traditional format module for residential installations, composed of cut G12 cells.

Equipped with 2 diodes on the central axis of the panel.

Ideal for medium-sized offgrid systems.

Technical data

  • Cells: 120 cut G12 cells
  • Dimensions: 1754 x 1098 x 30 mm
  • Weight: 21 kg
  • Glass: tempered, transparent, 3.2 mm
  • Cell encapsulant: EVA
  • Backsheet: multi-layer polyester
  • Frame: anodised aluminium, with mounting and drainage holes
  • Junction box: Certified according to IEC 62790, IP 68 approved
  • Code: FU400M SILK PREMIUM
garanzia-rendimento

Performance guarantee

Max. Decay: 0.5% year.
97% at the end of the first year
90% at the end of the 12th year
87% at the end of the 25th year



garanzia-prodotto

Product guarantee

15 years

Modulo fotovoltaico monocristallino 430W
FuturaSun FU 415/420/425/430 M Silk® Nova
394.99 KB

MONOCRYSTALLINE FV MODULE 430 W

Module made with 108 M10 n-type cells for maximum efficiency.

The best compromise between power and cost for medium and large installations.

With black frame.

Technical data

  • Cells: 108 M10 n-type cells
  • Dimensions: 1722 x 1134 x 30 mm
  • Weight: 20.8 kg
  • Glass: tempered, transparent, 3.2 mm
  • Cell encapsulant: EVA
  • Backsheet: multi-layer polyester
  • Frame: black anodised aluminium, with mounting and drainage holes
  • Junction box: Certified according to IEC 62790, IP 68 approved
garanzia-rendimento

Performance guarantee

Max. Decay from year 2 of 0.4%/year.
99% at the end of 1st year
92% at the end of the 20th year
89% at the end of year 25



garanzia-prodotto

Garanzia di prodotto

15 years
